السؤال
Transcribed Image Text:
*4-4. Determine the moment about point A of each of the
4 three forces acting on the beam.
4-5. Determine the moment about point B of each of the
three forces acting on the beam.
F₁ = 375 lb
F2 = 500 lb
A
8 ft-
5.
4
3
B.
0.5 ft
6 ft 5 ft-
30°
F3 = 160 lb
