السؤال
Transcribed Image Text:
5. A free vibration test is run to determine the stiffness and damping properties of an elastic
element. A 20-kg block is attached to the element. The block is displaced 1 cm and released.
The resulting oscillations are monitored with the results shown in the following figure.
Determine k and c for the element.
0.01
0.008
0.006
0.004
0.002
புரியாயா
-0.002
-0.004
-0.006
-0.008
-0.01
0
0.06 0.12 0.18
0.24
0.30
0.36
