السؤال
Transcribed Image Text:
Determine the magnitude T of the tension in the supporting cable and the
magnitude of the force on the pin at A for the jib crane shown. The beam
AB is a standard 0.5-m I-beam with a mass of 95 kg per meter of length.
0.25 m
A
+
↑
0.5 m
25
0.12 m
5 m
-1.5 -
10 kN
