السؤال
Transcribed Image Text:
P2.33 Find the transfer function for Y(s)/R(s) for the idle-
speed control system for a fuel-injected engine as
shown in Figure P2.33.
Air bypass
H₂(3)
R(s)
Speed command
Fuel
K's
K6
gain
Manifold
Dynamics
G₁(s)
G₂ls)
Gy(s)
Pressure
Y(s)
Engine
H₁(s)
speed
Spark gain
K₁
FIGURE P2.33 Idle speed control system.
