unding the Answers to odd-numbered problems are at the end of the book. CTION 3-1 The Inverter 1. The input waveform shown in Figure 3-74 is applied to an inverter. Draw the timi of the output waveform in proper relation to the input. VIN HIGH LOW பட 2. A network of cascaded inverters is shown in Figure 3-75. If a HIGH is applied to determine the logic levels at points B through FIGURE 3-75 ON 3-2 The AND Gate A 3. Determine the output, X, for a 2-input AND gate with the input waveforms shown in Show the proper relationship of output to inputs with a timing diagram. FIGURE 3-76 D
