السؤال
Transcribed Image Text:
4. For the rod end fitting shown in Figure 10-4, determine the critical fastener loads. (Hint: Balance the fitting in
both planes.) (14 points)
1.63R
++
+
9,000
.67
2.20
+
.160-
Figure 10-4 Rod End Fitting
9,000
.73
.200
