السؤال
Transcribed Image Text:
Example of Stresses:
Determine the average shear stress in the 20-mm-diameter pin
at A and the 30-mm-diameter pin at B that support the beam in
Fig. 1-21a.
(double shear)
130 kN
+
4 m
(single shear)
ERO-2D (3)
30 kl
Ax
7
Ay
MM
Σ
F=0
Particip
