السؤال
Transcribed Image Text:
2.43 In Fig. P2.43 pipe A contains gasoline (SG = 0.7), pipe B
contains oil (SG= 0.9), and the manometer fluid is mercury.
Determine the new differential reading if the pressure in pipe A is
decreased 25 kPa, and the pressure in pipe B remains constant. The
initial differential reading is 0.30 m as shown.
0.4 m
Oil
+3
+
0.3 m
-Mercury
Gasoline
FIGURE P2.43
