Q1. Figure 1 shows a cantilever beam ABC which is built-in at C and propped at A. The beam carries a uniformly-distributed load of intensity 2 kN/m between B and C. (1) What is the support reaction force at A? (ii) What is the support reaction force at C? (iii) What is the support reaction moment at C? (iv) What is the bending moment in the beam at B? [6 marks] [6 marks] [6 marks] [7 marks] 1.5 m 1.5 m +1 A B 2 kN/m Figure 1
