QUESTIONS 1. A ferromagnetic core is shown in figure. The relative permeability of core is 800 and the relative permeability of the air is 4.10 7H/m. The dimensions are shown in cm, and the depth of the core is 10 cm. There are two air gaps with 1mm length. If there are 1000 turns in the coil wrapped around the left leg of the core and if the current in the coil is 1 A. What are the flux values for the left and right legs of the core? What is the flux density in each air gap? Imm Z T → T 10cm Imm 60cm * 60cm 20cm 20cm Зост
