The diode circuit and its corresponding output characteristics (Vo-vs. i)are shown below. The resistance R₁ is 1 kn. Analyze the circuit using the constant voltage drop model with Vp = 0.7 V when the diode is conducting and the onset voltage for conduction is Vo= 0.5 V. (a) What is the mode of operation of D1 and D2 for (9 points) for I<I R₁ Vout in Dz D₁ Vout V. In 1. (b) What are the values of I-, 1+, and V. indicated in the transfer characteristics? (10 points) (c) What is the slope of the transfer characteristic for I<1_? (d) The signal input current is I= 2.0+ 0.5 sin(120) (mA). What is the peak of the small voltage signal that appears across each diode? (VT = 25.9 mV) Pane
