السؤال
Transcribed Image Text:
19MECH82I
Electronic Devices and Circuits
Problem-Based Project
Problem (1) (15%)
Sketch and clearly label the transfer characteristic of the circuit in Fig. 1 for-15V≤ vi≤+15V.
Assume that V=0.7V and Vz=6.8V.
VI
1 ΚΩ
www
O vo
Da
A
4
NA
Fig. 1
