السؤال
Transcribed Image Text:
You are asked to select a 301/302 stainless steel metal belt (i.e. find bmin) that runs over
two 200 mm metal pulleys with a coefficient of friction of 0.32 if the torque is to
be 4.3 N.m. The belt thickness is to be 0.1 mm. Make the selection for a life greater than 107
belt passes with smooth torque. Take Ks =1, ØTT, Modulus of elasticity of steel -193 GPa,
?Poisons ratio 0.285. Then bmin is equal to
=
mm 6.9024.a@
mm 1.0430.b
mm 1.2630.c
mm 2.0365.d O
check_circle الجواب — حل مفصل خطوة بخطوة
hourglass_top
🔒
الحل الكامل متاح للمشتركين
اشترك في أرشيف الأسئلة لعرض هذا الحل وآلاف الحلول المفصلة خطوة بخطوة من معلمين معتمدين.
