4.00 ME 353: Manufacturing Processes Homework 8 (20 Points) 3.00 2.50 0.35 2.00 0.25 1.00 0.50 1.00 1.50 2.00 3.00 4.00 5.35 R1.50 0.25 -0.25 6.00 7.00 8.00 The outline of the part in problem 1 is to be profile milled using a 1 inch diameter end mill with four teeth. The part is 0.50 in thick. Cutting speed = 200 ft/min and feed = 0.005 in/tooth. Use the lower left corner of the part as the origin in the x-y axis system. Two of the holes in the part have already been drilled and will be used for clamping the part during profile milling. Write the part program in G-code to create the part. Use absolute positioning. Use down-milling to create the part.
