السؤال
Transcribed Image Text:
In the marine crane shown, link CD is known to have a uniform
cross section of 50 X 150 mm. For the loading shown, determine
the normal stress in the central portion of that link.
15 m 25 m
3 m
35 m
B
C
SO Mg
15 m
D
